How Does a Hydraulic System Work?

hydraulic system
hydraulic system



A hydraulic system converts mechanical energy into fluid power by pressurizing liquid—typically oil—through a pump, then transmits that pressure through valves and lines to actuators like cylinders or motors that convert it back into mechanical force. This process relies on Pascal’s law, which states that pressure applied to a confined fluid transmits equally in all directions, enabling these systems to multiply force and perform heavy-duty work.



The Core Principle: Pascal’s Law in Action



The foundation of every hydraulic system traces back to 1653, when French mathematician Blaise Pascal discovered that pressure changes in an enclosed fluid transmit uniformly throughout that fluid. This principle enables hydraulic systems to achieve remarkable force multiplication.

When you apply 100 pounds of force to a 1-square-inch piston, you create 100 psi of pressure. If that pressure acts on a piston with 10 square inches of surface area, it generates 1,000 pounds of force. The system multiplies your input force by 10 times, though the larger piston moves only one-tenth the distance. This trade-off between force and distance follows the conservation of energy—you can’t create energy, but you can redirect it.

Unlike gases, hydraulic fluids are incompressible. When a pump pushes oil into a sealed cylinder, that oil has nowhere to go except to move the piston. This incompressibility makes hydraulic systems highly responsive and capable of holding loads in position without continuous power input. A hydraulic excavator can hold a 5-ton bucket suspended mid-air simply by closing a valve, with no energy expenditure beyond maintaining system pressure.







Modern hydraulic systems operate at pressures ranging from 1,000 to 10,000 psi, with some specialized applications exceeding these limits. At 3,000 psi, a 2-inch diameter cylinder generates over 9,400 pounds of force—enough to lift a full-size pickup truck. This power density explains why construction equipment, aircraft, and industrial machinery rely heavily on hydraulics despite their average system efficiency of 21 to 23 percent.



Essential Components and Their Functions



Hydraulic systems share five core components that work together to convert, transmit, and apply fluid power. Understanding each element clarifies how the complete system operates.

Reservoir: The hydraulic tank serves multiple purposes beyond fluid storage. It dissipates heat generated during operation, allows contaminants to settle out, and provides space for air bubbles to escape. Most reservoirs include baffles that slow fluid movement, enhancing separation of air and particulates. The tank also accommodates fluid volume changes as cylinders extend and retract, since one side of a cylinder holds more fluid than the other due to the piston rod occupying space.

Pump: This component creates flow, not pressure. The pump draws fluid from the reservoir and pushes it into the system, creating the flow rate measured in gallons per minute. Pressure develops only when that flow encounters resistance—from a load, a restriction, or a closed valve. Three main pump types dominate: gear pumps at 85% efficiency for simpler applications, vane pumps at 88% efficiency for moderate demands, and piston pumps reaching 95% efficiency for high-performance systems. A piston pump delivering 10 gpm at 95% efficiency wastes 80% less energy as heat compared to a gear pump at the same output.

Valves: Directional control valves route fluid to different actuators, while pressure relief valves protect the system from overpressure by diverting excess flow back to the reservoir. Flow control valves regulate actuator speed by restricting fluid volume. Modern electrohydraulic systems use solenoid-actuated valves that respond to electronic signals, enabling precise computer control. However, every valve creates a pressure drop that wastes energy—one reason the average hydraulic system achieves only 21% overall efficiency.

Actuators: Cylinders convert hydraulic pressure into linear motion, while motors convert it into rotation. A hydraulic cylinder with a 4-inch bore operating at 2,000 psi generates 25,000 pounds of force—explaining why excavators can rip through concrete and wheel loaders can lift multiple tons. Hydraulic motors provide high torque at low speeds, making them ideal for applications like concrete mixer drums and winches where electric motors would require extensive gearing.

Fluid: The liquid is more than a power transmission medium. It lubricates moving parts, removes heat, and seals clearances between components. Most systems use petroleum-based hydraulic oil, though biodegradable vegetable oils and fire-resistant fluids serve specialized applications. Viscosity matters significantly—oil that’s too thin leaks past seals, while thick oil increases friction losses. Temperature affects viscosity, which is why systems operating in extreme cold or heat require fluids formulated for those conditions.



The Energy Conversion Journey: Four Critical Stages



Hydraulic systems move energy through four distinct phases, with losses occurring at each transition. This framework reveals both the power and limitations of hydraulic technology.

Stage 1: Mechanical to Hydraulic (The Pump): An electric motor or engine drives the pump shaft, converting rotary mechanical power into hydraulic flow and pressure. A well-maintained piston pump operates at 95% efficiency under ideal conditions, but most systems use gear pumps at 85% efficiency. Right here, in the first energy conversion, 5 to 15 percent of input energy becomes waste heat. A 100 HP input yields 85 to 95 HP of hydraulic power—a loss that compounds through subsequent stages.

Stage 2: Hydraulic Transmission (Valves and Lines): Fluid flows through control valves and lines to reach actuators. Each valve creates a pressure drop, and longer lines increase friction losses. A typical directional control valve drops 50 to 150 psi, which represents energy converted to heat rather than useful work. Undersized hoses magnify this effect—running 20 gpm through a 1/2-inch hose instead of a 3/4-inch line nearly doubles the pressure drop. These losses explain why load-sensing systems, which minimize unnecessary pressure, can improve overall efficiency by 20 to 30 percent.

Stage 3: Hydraulic to Mechanical (The Actuator): Cylinders and motors convert hydraulic energy back to mechanical power. A hydraulic motor in good condition operates at 80 to 90% efficiency. The volumetric efficiency (minimizing internal leakage) and mechanical efficiency (reducing friction) both matter. As pressure rises and temperature increases, internal leakage grows, reducing volumetric efficiency. This is particularly problematic in mobile equipment, where smaller reservoirs lead to higher operating temperatures than industrial systems experience.

Stage 4: Mechanical Work (The Application): The actuator moves a load—lifting, pushing, pulling, or rotating. The useful work extracted depends on how well the system matches the application. Using a 50-ton cylinder to lift a 5-ton load wastes energy, as does running a pump at full capacity when the application needs only 30% of maximum flow. Variable displacement pumps address this by adjusting their output to match demand, delivering only the pressure and flow required.

Multiply the efficiencies: 0.85 (pump) × 0.90 (transmission) × 0.85 (motor) = 0.65 or 65% overall. Factor in valve losses and system design inefficiencies, and you arrive at the industry-observed average of 21 to 23 percent. This means only about one-fifth of the input energy performs useful work—the rest dissipates as heat. Yet hydraulics remain essential because they deliver unmatched power density and controllability for their size and weight.



hydraulic system
hydraulic system



Open vs. Closed Systems: Design Architecture Matters



The fundamental system architecture influences efficiency, complexity, and application suitability. Two main configurations dominate the market.

Open Center Systems: The pump runs continuously, circulating fluid through the system. When valves are in neutral position, fluid returns directly to the reservoir at low pressure. Open systems use fixed-displacement pumps and directional control valves to route flow to various actuators. They’re simpler, less expensive, and easier to maintain, making them popular for construction equipment and agricultural machinery. However, the pump always works against some resistance, even when no actuator moves, creating constant heat generation.

Closed Loop Systems: The return line from actuators connects directly back to the pump inlet rather than the reservoir. A charge pump supplies cool, filtered oil to replenish leakage and maintain low-side pressure. Closed systems typically use variable displacement pumps or motors, enabling more efficient power transmission. Since fluid circulates in a closed loop, less fluid volume is needed, allowing smaller reservoirs. They excel in mobile applications like hydrostatic transmissions for vehicles. The trade-off is higher initial cost and more complex maintenance.

Load-sensing systems represent an evolution that bridges both architectures. The pump adjusts its output to maintain a small pressure differential—typically 200 to 300 psi—above the load requirement. When an actuator needs 2,000 psi, the pump delivers 2,200 psi. When demand drops to 500 psi, so does pump pressure. This responsiveness eliminates the energy waste of maintaining constant high pressure, reducing heat generation and improving overall system efficiency by 25 to 35 percent compared to conventional open-center systems.



Real-World Performance: From Construction to Aerospace



The global hydraulics market reached $38 to $46 billion in 2024, with construction equipment representing 39% of demand. Understanding how systems perform in actual applications reveals both their capabilities and ongoing challenges.

Volvo Construction Equipment’s excavators equipped with Independent Metering Valve Technology demonstrate measurable improvements. By electronically controlling each cylinder port independently rather than mechanically coupling them, IMVT achieved 25% better fuel efficiency and 20% higher productivity in field testing. An EC550 excavator with a larger bucket consumed less fuel than an EC480 while accomplishing more work—reversing the traditional power-versus-efficiency trade-off. The closed-center valve control stops or minimizes flow through the main control valve when no hydraulic demand exists, eliminating a major source of waste heat.

Industrial applications face different demands. Manufacturing presses, injection molding machines, and automated assembly lines often require holding force with minimal movement. Hydraulic systems excel here because they can maintain pressure indefinitely by simply closing a valve—no power input required beyond overcoming internal leakage. A 500-ton press holds a part in position while adhesive cures, using essentially zero energy for the holding phase. Electric actuation would require continuous power to prevent servo motor drift.

Aerospace systems operate under extreme constraints. Aircraft hydraulic systems typically run at 3,000 to 5,000 psi, using fire-resistant fluids to minimize safety risks. Landing gear, flight control surfaces, and braking systems all depend on hydraulics for their high power-to-weight ratio. A Boeing 777’s hydraulic system delivers over 400 HP through components weighing less than a comparable electric system would. Redundant circuits ensure that if one hydraulic system fails, backup systems maintain control of critical functions.

The efficiency challenge persists across all applications. Oak Ridge National Laboratory research found that most hydraulic systems operate at only 23% efficiency, wasting billions of kWh annually. Modern solutions include electro-hydraulic integration, where electric motors drive pumps only when needed and at variable speeds matching demand. Some systems recover energy from descending loads—capturing the potential energy of a lowering excavator boom and returning it to the system or storing it in accumulators.



Common Failure Modes and Prevention



Between 80 and 90 percent of hydraulic problems stem from contamination, according to industry analysis. Understanding failure patterns helps prevent costly downtime.

Fluid Contamination: Particulates, water, and air cause accelerated wear, corrosion, and performance degradation. A single teaspoon of dirt in a 100-gallon system can destroy pumps and valves. Filters remove particles, but they must be changed before they clog—a blocked filter forces oil through the bypass valve, returning unfiltered fluid to the system. Water enters through condensation in reservoirs experiencing temperature swings or through damaged seals. Even 0.1% water content accelerates oil oxidation and causes rust in steel components.

Temperature Extremes: Hydraulic fluid becomes less viscous as temperature rises, increasing internal leakage and reducing efficiency. Above 180°F, seals degrade and oil oxidizes, forming sludge that clogs orifices and sticks valves. Cold oil thickens, forcing pumps to work harder and potentially causing cavitation. Systems operating in extreme environments need heaters to warm cold oil or coolers to dissipate excess heat. Monitoring fluid temperature provides an early warning of problems—an unexplained rise often indicates internal leakage generating friction heat.

Aeration and Cavitation: Air in the system compresses and expands, creating noise, erratic actuator movement, and heat. When air bubbles collapse under pressure, they generate shock waves that erode metal surfaces—a process called cavitation. Cavitation also occurs when pump inlet pressure drops too low, causing the fluid itself to vaporize. Proper reservoir design, ensuring pump inlet lines are sized correctly and checking for leaks in suction plumbing prevents these issues.

Seal and Component Wear: Every moving seal creates friction, gradually wearing grooves in cylinder walls and piston rods. Contaminated fluid accelerates this wear dramatically. Scratched rods damage seals, leading to external leaks that waste fluid and create safety hazards. Regular inspection catches minor issues before they escalate—replacing a $50 seal beats rebuilding a $5,000 cylinder. Using the manufacturer-specified fluid and maintaining proper viscosity extends component life significantly.

Proactive maintenance reduces failures by 60 to 70 percent compared to reactive approaches. This means scheduled fluid analysis, filter changes based on pressure differential rather than time alone, and infrared temperature monitoring to identify components with excessive internal leakage before they fail completely.



hydraulic system
hydraulic system



Frequently Asked Questions



Why use hydraulics instead of electric actuators?

Hydraulic systems deliver much higher power density—more force per pound of weight—than electric motors and gearing. A 2-inch hydraulic cylinder weighs a few pounds but generates over 6,000 pounds of force at 2,000 psi. An electric actuator producing equivalent force would require a large motor, reduction gearing, and stronger structural components, resulting in a system several times heavier and more expensive. For applications needing immense force with compact packaging, hydraulics remain the practical choice.

Can hydraulic systems be energy efficient?

Individual components can achieve 90 to 95 percent efficiency, but complete systems average 21 to 23 percent due to multiple energy conversions and valve losses. However, efficiency depends heavily on system design and application matching. Load-sensing pumps, variable displacement components, and energy recovery systems can double overall efficiency compared to conventional designs. The trend toward electro-hydraulic integration—using variable-speed electric motors to drive pumps precisely matching demand—shows promise for substantial efficiency gains.

How long do hydraulic systems last?

Well-maintained systems operate for decades. The critical factor is fluid cleanliness—keeping contamination below ISO 4406 cleanliness code 16/14/11 extends component life five to ten times compared to systems at 20/18/15 code levels. Regular fluid analysis, proper filter maintenance, and keeping operating temperatures below 140°F ensure long service life. Many industrial hydraulic systems run 50,000 to 100,000 hours between major overhauls when properly cared for.

What causes hydraulic system noise?

Cavitation produces a characteristic knocking sound as vapor bubbles collapse. Aeration causes a whining or growling noise as compressed air releases pressure. Worn pumps create more noise as internal clearances increase. Loose mounting hardware vibrates, and undersized lines cause fluid velocity to increase, generating turbulence noise. Each noise type indicates a specific problem—diagnosing the sound pattern helps identify the root cause quickly.



Looking Forward



Hydraulic technology continues evolving beyond its 370-year-old foundation. Digital hydraulics—where solenoid-actuated poppet valves replace traditional spool valves—offers near-instantaneous response and eliminates some efficiency losses. Smart sensors monitor pressure, temperature, and flow in real-time, enabling predictive maintenance that prevents failures before they occur. Energy recovery systems capture potential energy from lowering loads, storing it in accumulators or feeding it back to electric drive motors in hybrid systems.

The core physics remains unchanged: Pascal discovered in 1653 that confined fluids transmit pressure equally in all directions. What’s different is how we apply that principle. Modern control systems, advanced materials, and innovative architectures are pushing hydraulic efficiency higher while maintaining the unmatched power density that makes these systems indispensable. As pressure toward energy efficiency intensifies across all industries, expect to see hydraulic technology become both more sophisticated and more tightly integrated with electronic controls. The fundamental concept stays the same—pressurized fluid moving through pipes and cylinders—but the execution grows smarter each year.
